SECTION 25: INSTRUMENT SPECIFICATIONS InSpec Sampler Controller
102
SECTION 25: INSTRUMENT SPECIFICATIONS
25.1 GENERAL SPECIFICATIONS
Design Area
Item
Description
Physical
Size (mm)
130 x 220 x 165 (W x H x D) Approx. inc. PE stud
Depth including connectors approx. 220mm
Weight
1.8 kg
Wire Connections
IEC Socket: 3 x 2.5mm² (3 x 14 AWG) max.
Other: 0.08mm² to 2.5mm² (28 – 12 AWG)
Operating
Environment
Equipment Class
I
Installation Category
II
Pollution Degree
22
Operating Temperature
5°C to 40 °C (41°F to 104°F)
Relative Humidity
80% up to 31°C decreasing linearly to 50% at
40°C
IP Rating
IP42 at front and IP20 at rear of unit.
Altitude
2000 metres max. (6562 feet)
User Interface
Display
20 Character x 2 lines.
LED Indicators
4 multicolour LED’s
Keys
21
Power Supply
Voltage, Frequency
AC : 100 to 240 V AC, 50/60 Hz
DC : 24V DC ± 10%
Power Consumption
15 Watts Max.
Inrush Current
20A @ 115V AC, 40 @ 230V AC (Full Load)
Fuses
2 off T 500mA H 250V AC
Relay Outputs
Quantity
4
Contact Form
SPST – NO
Installation Category
III
Max. Switching Voltage
250V AC, 30V DC
Max. Switching Current
2 Amps
Over Voltage Protection
275V rms max. MOV (350V DC max.)
Digital I/O Points
Quantity
4
Over voltage Protection
26VDC TVS
When configured as an output
Contact Form
Solid State Relay
Load Voltage
24V DC
Continuous Load Current
0.12A
Max. On Resistance
35 ohms (Typical 23.5 ohms)
Max. Leakage Current
1uA (in off state)
Over Current Protection
Cut off Current: 160 to 240mA
Detection Time: 50us
When configured as an Input
Input Type
Volt-free contact
Max. Excitation Current
2.4mA
Analogue Outputs
Quantity
2
Output Type
4-20mA Current Source
(24V DC Loop Supply)
2
Pollution Degree 2 – Normally only non-conductive POLLUTION occurs. Occasionally, however, a
temporary conductivity caused by condensation must be expected.
