Sensia JISKOOT InSpec Sampler User Manual

Appendix B: Installation Sequence (Safe Area Unit) InSpec Sampler Controller
122
e) Ensure that latches located at the top and bottom of
the unit are undone and that the arms are inside the
unit as shown.
f) Insert the main body in the correct size cut-
out.
g) Using a 4mm Allen Key tighten the two latches. The
arms should automatically swing out and grip the
mounting panel.
h) Reconnect the ribbon cable from the front
panel and then hook the front panel on the
body of the instrument.
i) Locate the front panel fixing screw with the main
body in the panel and tighten with a 2.5mm Allen
Key.
