Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
9
Error and alarm messages
Diagnostics
Fatal error code F1503/1504, error 108, subcode 027/028
Error message CRC of firmware configuration data invalid.
Remedy Replace the DCS..B option and send it together with error number to SEW Service for
further inspection.
Fatal error code F1505/1506, error 108, subcode 029/030
Error message Error during internal transmission of firmware configuration data.
Remedy Replace the DCS..B option and send it together with error number to SEW Service for
further inspection.
Fatal error code F1601, error 108, subcode 031
Error message Faulty range check of device description.
Cause Faulty configuration data of the device description.
Remedy • Reload the configuration data. Next switch the DCS..B option off and on again.
• Consult SEW Service for the proper MOVISAFE
®
software version.
Fatal error code F1603, error 108, subcode 032
Error message Faulty range check of access data.
Cause Faulty configuration data of the device description.
Remedy • Reload the configuration data. Next switch the DCS..B option off and on again.
• Consult SEW Service for the proper MOVISAFE
®
software version.
Fatal error code F1605, error 108, subcode 033
Error message Faulty EMU range check.
Cause Fault configuration data of the EMU function.
Remedy • Undo the changes in the EMU configuration or enter new values.
• Reload the configuration data. Next switch the DCS..B option off and on again.
• If the error still persists, consult SEW Service for the proper MOVISAFE
®
software
version.
Fatal error code F1607, error 108, subcode 034
Error message Faulty PSC range check.
Cause Faulty configuration data of the PSC function.
Remedy • Undo the changes in the PSC configuration or enter new values.
• Reload the configuration data. Next switch the DCS..B option off and on again.
• If the error still persists, consult SEW Service for the proper MOVISAFE
®
software
version.
Fatal error code F1609, error 108, subcode 035
Error message Faulty ESS range check.
Cause Faulty configuration data of the ESS function.
Remedy • Undo the changes in the ESS configuration or enter new values.
• Reload the configuration data. Next switch the DCS..B option off and on again.
• If the error still persists, consult SEW Service for the proper MOVISAFE
®
software
version.
