Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
9
Error and alarm messages
Diagnostics
Alarm code A3614, error 109, subcode 073
Alarm message Faulty switching behavior of the HISIDE driver DO1_P.
Cause DC 24 V short circuit at digital output DO1_P (X82:3).
Remedy Check wiring at the digital output.
Alarm code A3615, error 109, subcode 074
Alarm message Undervoltage test WD for LOSIDE driver.
Cause DC 0 V short circuit at on of the DC 0 V digital outputs (DO0_M, DO1_M, DO2_M).
Remedy Check wiring at digital outputs.
Alarm code A3616, error 109, subcode 075
Alarm message Undervoltage test WD for HISIDE driver.
Cause DC 24 V short circuit at on of the DC 24 V digital outputs (DO0_P, DO1_P, DO2_P).
Remedy Check wiring at digital outputs.
Alarm code A4001/4002, error 109, subcode 076/077
Alarm message CCW and CW monitoring of DMC function activated simultaneously.
Cause Multiple activation of the DMC function.
Remedy It is important that only one "Enable" is activated in the control of the DMC function.
Alarm code A4601/4602, error 109, subcode 078/079
Alarm message CCW and CW monitoring range of the OLC function activated simultaneously.
Cause Multiple activation of the OLC function.
Remedy It is important that only one "Enable" is activated in the control of the OLC function.
Alarm code A4901/4902, error 109, subcode 080/081
Alarm message CCW and CW monitoring of the JSS function was activated simultaneously.
Cause Multiple activation of the JSS function.
Remedy It is important that only one "Enable" is activated in the control of the JSS function.
Alarm code A6701/6702, error 109, subcode 082/083
Alarm message Timeout error MET.
Cause Input element with time monitoring is faulty.
Remedy • Check wiring of input element
• Input element faulty
Alarm code A6703/6704, error 109, subcode 084/085
Alarm message Timeout error MEZ.
Cause Two-hand operation with time monitoring is faulty.
Remedy • Check wiring of input element
• Input element faulty
