Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
55
5
Connecting binary outputs
Installation
Example: Signal pattern of binary outputs (e.g. DO0_P and DO0_M) combined in a
group:
Example: Signal pattern of an individual P binary output (e.g. DO0_P):
9007201568874379
9007201568878603
t
High
Low
t
High
Low
DO0_P
DO0_M
t
1
< 500μs t
1
< 500μs
t
1
< 500μs
t
1
< 500μs
t
High
Low
DO0_P
t
1
< 500μs
t
1
< 500μs
