33
Adjusting and
Controlling
Multi
1 From the “Control Option” menu, select “Configuration”.
2 Select “ALL” if you want to turn on all the projectors at
once or “Delayed” if you want to turn on the projectors
one at a time in order.
3 Click the “OK” button.
Group Projector: This is for controlling grouped projectors one group
at a time. The adjustment items in this frame are
reflected for all the projectors in the selected group.
5 Select the Power ON/OFF
6 Select the “Input Mode” from RGB1 to 3, or Video 1 to 2.
7 To make “Volume” adjustment
The volume of the projector with the lowest ID number in the group
is displayed.
8 Select “AV Mute” ON/OFF
9 To make “Black Screen”
0 Select “Mute” ON/OFF
q Group List : Displays a list of all the connected groups.
The information displayed in “Group List” is as follows:
● Power : When the power supplies of all the projectors
belonging to the group are ON, the green icon
is displayed. When they are OFF, the red icon is
displayed.
When the power supplies of some projectors are
ON and others are OFF, the yellow icon is
displayed.
● No : Group Number
● Group : Group Name
● Input Mode : Selected Input Mode
● Vol : Volume
In “Input Mode” and “Vol”, the value of the projector whose ID
Number is the smallest of all the projectors belonging to the group,
is displayed.
(When controlling the projectors without using an ID Number,
the value of the projector whose COM Port Number is the smallest
in the group is displayed.)
w Refresh all the display information.
e Refresh the display information for the selected group.
r Jump to “Advanced Control for Adjustment” to conduct adjustments
for the selected group.
To Next Page
