- 122 -
Loop break alarm
When Loop break alarm is selected in [Event output EV allocation],
detects actuator trouble (heater burnout, heater adhesion) or sensor
burnout.
Loop break alarm time
0 to 200 minutes
Loop break alarm span
Thermocouple, RTD input without decimal point: 0 to 150 ( )
Thermocouple, RTD input with decimal point: 0.0 to 150.0 ( )
DC voltage, current input: 0 to 1500 (The placement of the decimal
point follows the selection.)
Output
EV output for which Loop break alarm output is selected in [Event
output EV allocation].
Time signal output
When Time signal output is selected in [Event output EV allocation],
Time signal output activates during Time signal output ON time within
one pattern total time.
Time signal output ON time follows Time signal output OFF time after
the program control starts.
During Wait action or Program control Hold, progress time of Time
signal output stops.
When step time is changed during program control RUN, Time signal
output timing is re-calculated using the pattern time after change.
Output during AT
When ‘Output during AT’ is selected in [Event output EV allocation],
turns ON during AT.
Pattern end output
When Pattern end output is selected in [Event output EV allocation],
Pattern end output is turned ON during Pattern end output time after
program control is finished, and the SV Display flashes
p.end
.
By pressing the STOP key for approximately 1 second, Pattern end
output is turned OFF, and the unit returns to Program control STOP (in
Standby). If Pattern end output time is set, Pattern end output is
automatically turned OFF after Pattern end output time has expired. The
unit returns to Program control STOP (in Standby).
RUN output
When ‘RUN output’ is selected in [Event output EV allocation],
turns ON during program control RUN.
Data clear function
During program control STOP (in Standby), if the , and STOP
keys (in that order) are pressed together for approx. 3 seconds, the PV
Display indicates clr/, and the unit enters [Data clear Yes/No].
Select yes/ (Data clear Yes), and press the MODE key. The PV
Display indicates init for approx. 3 seconds, and all data will return
to factory default values.
