7. Basic Settings and Operation
7.1 Procedure of Basic Settings and Operation
(Fig. 7.1-1)
Power ON
Control parameters
(pp.54 - 62)
Wait parameters
(pp.63 - 66)
Pattern setting
(pp.43 -47)
AT Perform
(pp.99 - 101)
Test operation
RUN
Sets program pattern.
Turn the load power ON, and
perform test operation.
Performs AT.
Program pattern
setting
PID block, Wait
value setting
Sets PID, ARW, etc.
Sets Wait value, and Wait function
Enabled/Disabled for each step.
