Shinko PCB1 User Manual

- 145 -
13.6 Engineering Setting Mode 1
Characters,
Factory Default
Setting Item, Setting Range Data
lock
/ ----
Set value lock
Change via Keypad
Change
via Software
Communication
---- Unlock All set values can be
changed.
All set values can
be changed.
loc1 Lock 1 Only ‘Set value lock’ can
be changed.
loc2 Lock 2 Setting items selected in
[Changeable in Set
value lock] can be
changed.
Only ‘Set value lock’ can
be changed.
loc3 Lock 3 All set values can be
changed.
Setting items –
except Input type –
can be changed
temporarily via
software
communication.
However, if power is
turned
ON again, the
set values revert
to
the values before
Lock 3, 4 or 5 was
selected.
loc4 Lock 4 Only ‘Set value lock’
can be changed. Other
setting items cannot be
changed.
loc5 Lock 5 Setting items selected in
[Changeable in Set
value lock] can be
changed.
Only ‘Set value lock’ can
be changed.
lose
/ sv//
Changeable in Set value lock
sv// Step SV, Step time can be changed.
svev Step SV, Step time, EV alarm value can be changed.
sok/
/ 1.000
Sensor correction coefficient
Setting range:
-10.000 to 10.000
so//
/ //0.0
Sensor correction
Setting range: -1000.0 to 1000.0 ( )
DC voltage, current inputs: -10000 to 10000 (The placement of the
decimal point follows the selection.)
filt
/ //0.0
PV filter time constant
Setting range: 0.0 to 10.0 seconds
cmsl
/ noml
Communication protocol
noml Shinko protocol
svt/ Set value digital transmission (Shinko protocol)
svtr Set value digital reception (Shinko protocol)
moda Modbus ASCII mode
modr Modbus RTU mode
Available when C5W or C5 option is ordered.
