13.2 Pattern Setting Mode
Characters,
Factory Default
Setting Item, Setting Range Data
temp
1 ///0
PTN/STEP
indicator 1 lights.
Step 1 SV
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 1 lights.
Step 1 time
----
,
00:00 to 99.59 (Time unit follows the selection in [Step time
unit].)
If the key is pressed at 00:00, ---- will be indicated.
If ---- is set, Fixed value control will be performed using Step 1 SV.
_pid
1 ///1
PTN/STEP
indicator 1 lights.
Step 1 PID block number
1 to 10
temp
1 ///0
PTN/STEP
indicator 2 lights.
Step 2 SV
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 2 lights.
Step 2 time
----
,
00:00 to 99.59 (Time unit follows the selection in [Step time
unit].)
If the key is pressed at 00:00, ---- will be indicated.
If ---- is set, Fixed value control will be performed using Step 2 SV.
_pid
1 ///1
PTN/STEP
indicator 2 lights.
Step 2 PID block number
1 to 10
temp
1 ///0
PTN/STEP
indicator 3 lights.
Step 3 SV
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 3 lights.
Step 3 time
----
,
00:00 to 99.59 (Time unit follows the selection in [Step time
unit].)
If the key is pressed at 00:00, ---- will be indicated.
If ---- is set, Fixed value control will be performed using Step 3 SV.
_pid
1 ///1
PTN/STEP
indicator 3 lights.
Step 3 PID block number
1 to 10
