- 135 -
Characters,
Factory Default
Setting Item, Setting Range Data
temp
1 ///0
PTN/STEP
indicator 4 lights.
Step 4 SV
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 4 lights.
Step 4 time
----
,
00:00 to 99.59 (Time unit follows the selection in [Step time
unit].)
If the key is pressed at 00:00, ---- will be indicated.
If ---- is set, Fixed value control will be performed using Step 4 SV.
_pid
1 ///1
PTN/STEP
indicator 4 lights.
Step 4 PID block number
1 to 10
temp
1 ///0
PTN/STEP
indicator 5 lights.
Step 5 SV
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 5 lights.
Step 5 time
----
,
00:00 to 99.59 (Time unit follows the selection in [Step time
unit].)
If the key is pressed at 00:00, ---- will be indicated.
If ---- is set, Fixed value control will be performed using Step 5 SV.
_pid
1 ///1
PTN/STEP
indicator 5 lights.
Step 5 PID block number
1 to 10
temp
1 ///0
PTN/STEP
indicator 6 lights.
Step 6 SV
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 6 lights.
Step 6 time
----
,
00:00 to 99.59 (Time unit follows the selection in [Step time
unit].)
If the key is pressed at 00:00, ---- will be indicated.
If ---- is set, Fixed value control will be performed using Step 6 SV.
_pid
1 ///1
PTN/STEP
indicator 6 lights.
Step 6 PID block number
1 to 10
