Shinko PCB1 - Page 136

- 136 -
Characters,
Factory Default
Setting Item, Setting Range Data
temp
1 ///0
PTN/STEP
indicator 7 lights.
Step 7 SV
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 7 lights.
Step 7 time
----
,
00:00 to 99.59 (Time unit follows the selection in [Step time
unit].)
If the key is pressed at 00:00, ---- will be indicated.
If ---- is set, Fixed value control will be performed using Step 7 SV.
_pid
1 ///1
PTN/STEP
indicator 7 lights.
Step 7 PID block number
1 to 10
temp
1 ///0
PTN/STEP
indicator 8 lights.
Step 8 SV
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 8 lights.
Step 8 time
----
,
00:00 to 99.59 (Time unit follows the selection in [Step time
unit].)
If the key is pressed at 00:00, ---- will be indicated.
If ---- is set, Fixed value control will be performed using Step 8 SV.
_pid
1 ///1
PTN/STEP
indicator 8 lights.
Step 8 PID block number
1 to 10
temp
1 ///0
PTN/STEP
indicator 9 lights.
Step 9 SV
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 9 lights.
Step 9 time
----
,
00:00 to 99.59 (Time unit follows the selection in [Step time
unit].)
If the key is pressed at 00:00, ---- will be indicated.
If ---- is set, Fixed value control will be performed using Step 9 SV.
_pid
1 ///1
PTN/STEP
indicator 9 lights.
Step 9 PID block number
1 to 10
