- 156 -
• PID block includes: OUT1 proportional band, Integral time, Derivative time, ARW, OUT2 proportional
band
10 types of PID block (1 – 10) can be set.
• Wait function Enabled or Disabled can be selected for each step.
14.2 Making Data Table
Please make a copy of Data Table (p.158), and follow the procedure below.
(1) Write data for block numbers in Control parameter setting mode, by referring to the PID block numbers
in the Program pattern table.
(2) For Wait value and other setting items, write the data in the table if required.
About PID block settings
If program pattern is not set for a step, its PID block number becomes 1 (factory default). We highly
recommend that you leave the factory default values of PID block 1 as they are, and set the values
from PID block 2.
• Example of PID block setting
PID Block
number
OUT1
P-band
Integral
time
Derivative
time
ARW
OUT2
P-band
1 10 200 sec 50 sec 50% 10
2 30 240 sec 60 sec 35% 10
3 50 340 sec 85 sec 40% 10
• Example of Wait value setting
Wait value 10
Wait value is common to all steps for each pattern.
• Example of other setting items
Setting items Data
OUT1 proportional cycle 15 sec
OUT2 proportional cycle 15 sec
Number of repetitions 1
Pattern link Pattern link Disabled
Communication protocol Shinko protocol
Instrument number 1
Communication speed 38400 bps
Data bit/Parity 7 bits/Even
Stop bit 1 bit
Response delay time 10 ms
