Shinko PCB1 - Engineering Setting Mode 2

- 147 -
13.7 Engineering Setting Mode 2
Characters,
Factory Default
Setting Item, Setting Range Data
sens
/ k//C
Input type
k//C K -200 to 1370
k//.C
K -200.0 to 400.0
j//.C
J -200 to 1000
r//C
R 0 to 1760
s//C
S 0 to 1760
b//C
B 0 to 1820
e//C
E -200 to 800
t//.C
T -200.0 to 400.0
n//C
N -200 to 1300
pl2C
PL- 0 to 1390
c//C
C(W/Re5-26) 0 to 2315
pt/.C
Pt100 -200.0 to 850.0
jpt.C
JPt100 -200.0 to 500.0
pt/C
Pt100 -200 to 850
jptC
JPt100 -200 to 500
k//f K -328 to 2498
k//.f K -328.0 to 752.0
j//f J -328 to 1832
r//f R 32 to 3200
s//f S 32 to 3200
b//f B 32 to 3308
e//f E -328 to 1472
t//.f T -328.0 to 752.0
n//f N -328 to 2372
pl2f PL- 32 to 2534
c//f C(W/Re5-26) 32 to 4199
pt/.f Pt100 -328.0 to 1562.0
jpt.f JPt100 -328.0 to 932.0
pt/f Pt100 -328 to 1562
jptf JPt100 -328 to 932
420a 4 to 20 mA -2000 to 10000
020a 0 to 20 mA -2000 to 10000
0/1v 0 to 1 V -2000 to 10000
0/5v 0 to 5 V -2000 to 10000
1/5v 1 to 5 V -2000 to 10000
010v 0 to 10 V -2000 to 10000
stlh
/ 1370
Scaling high limit
Setting range: Scaling low limit to Input range high limit
DC voltage, current inputs: -2000 to 10000 (The placement of the
decimal point follows the selection.)
