Shinko PCB1 - Page 148

- 148 -
Characters,
Factory Default
Setting Item, Setting Range Data
stll
/ -200
Scaling low limit
Setting range: Input range low limit to Scaling high limit
DC voltage, current inputs: -2000 to 10000 (The placement of the
decimal point follows the selection.)
dp//
/ ///0
Decimal point place
///0 No decimal point
//0.0 1 digit after decimal point
/0.00 2 digits after decimal point
0.000 3 digits after decimal point
Available when DC voltage or current input is selected in [Input type].
evo1
/ /000
Event output EV1 allocation
/000 No event
/001 Alarm output, High limit alarm
/002 Alarm output, Low limit alarm
/003 Alarm output, High/Low limits alarm
/004
Alarm output, High/Low limits independent alarm
/005
Alarm output, High/Low limit range alarm
/006
Alarm output, High/Low limit range independent alarm
/007 Alarm output, Process high alarm
/008 Alarm output, Process low alarm
/009
Alarm output, High limit with standby alarm
/010
Alarm output, Low limit with standby alarm
/011
Alarm output, High/Low limits with standby alarm
/012
Alarm output, High/Low limits with standby independent
alarm
/013 Heater burnout alarm output (When C5W, EIW or W option
is ordered)
/014 Loop break alarm output
/015 Time signal output
/016 Output during AT
/017 Pattern end output
/018 Output by communication command
/019 RUN output
When
/001
(High limit alarm) to
/012
(High/Low limit with standby
independent alarm) or
/015
(Time signal output) is selected, one output can be
set to one event output.
When
/
013
(Heater burnout alarm output),
/014
(Loop break alarm),
/016
(Output during AT) to
/019
(RUN output) are selected, each output is common to
multiple event outputs.
a1za
/ no//
EV1 alarm value 0 Enabled/Disabled
no// Disabled
yes/ Enabled
Available when any alarm from /0 01 (High limit alarm) to /012 (High/Low limits
with standby independent alarm) is selected in [Event output EV1 allocation] -
excluding /007 (Process high alarm) and /008 (Process low alarm].
