Shinko PCB1 User Manual

- 71 -
8.6 Setting Items in Engineering Setting Mode 2
In Engeering setting mode 2, the following setting items can be set:
Input type, Scaling high limit, Scaling low limit, Event output EV allocation, Step time unit,
Power restore action, etc.
Setting data is common to all patterns.
• How to enter Engineering setting mode 2
In RUN mode, press the , and MODE key (in that order) together for approx. 3 seconds
to enter Engeering setting mode 2.
Setting items in Engeering setting mode 2 are shown below.
Characters,
Factory Default
Setting Item, Function, Setting Range
sens
/ k//C
Input type
• Selects an input type from thermocouple (10 types), RTD (2 types), direct
current (2 types) and DC voltage (4 type), and the unit / .
• When changing the input from DC voltage to other inputs, remove the
sensor connected to this controller first, then change the input. If the
input is changed with the sensor connected, the input circuit may break.
• When changing an input type, refer to Section “9.6 Items to be Initialized by
Changing Settings” (p.104).
• Selection item:
k//C K -200 to 1370
k//.C
K -200.0 to 400.0
j//.C
J -200 to 1000
r//C
R 0 to 1760
s//C
S 0 to 1760
b//C
B 0 to 1820
e//C
E -200 to 800
t//.C
T -200.0 to 400.0
n//C
N -200 to 1300
pl2C
PL- 0 to 1390
c//C
C(W/Re5-26) 0 to 2315
pt/.C
Pt100 -200.0 to 850.0
jpt.C
JPt100 -200.0 to 500.0
pt/C
Pt100 -200 to 850
jptC
JPt100 -200 to 500
k//f K -328 to 2498
k//.f K -328.0 to 752.0
j//f J -328 to 1832
r//f R 32 to 3200
s//f S 32 to 3200
b//f B 32 to 3308
e//f E -328 to 1472
