- 70 -
Characters,
Factory Default
Setting Item, Function, Setting Range
cmsp
/ //96
Communication speed
• Selects a communication speed equal to that of the host computer.
• Selection item:
//96 9600 bps
/192 19200 bps
/384 38400 bps
Available when C5W or C5 option is ordered.
cmft
/ 7evn
Data bit/Parity
• Selects data bit and parity equal to those of the host computer.
• Selection item:
8non 8 bits/No parity
7non 7 bits/No parity
8evn 8 bits/Even
7evn 7 bits/Even
8odd 8 bits/Odd
7odd 7 bits/Odd
Available when C5W or C5 option is ordered.
cmst
/ ///1
Stop bit
• Selects the stop bit equal to that of the host computer.
• Selection item:
///1 1 bit
///2 2 bits
Available when C5W or C5 option is ordered.
cmdy
/ //10
Response delay time
• Response from the controller can be delayed after receiving command from
the host computer.
If Response delay time is changed via software communication, the changed
delay time will be reflected from that response data.
• Setting range: 0 to 1000 ms
Available when C5W or C5 option is ordered.
sv_b
/ ///0
SVTC bias
• SV adds SVTC bias value to the value received by the SVTC command.
• Setting range: 20% of input span
DC voltage, current inputs: 20% of scaling span (The placement of the
decimal point follows the selection.)
Available when C5W, C5 option is ordered, and when svtr [Set value digital reception
(Shinko protocol)] is selected in [Communication protocol].
At this stage, settings for Engineering setting mode 1 are complete.
Press the RST key. The unit reverts to RUN mode.
