Shinko PCB1 User Manual

- 86 -
9. Operation
9.1 Performing Program Control
9.1.1 Performing Program Control
(1) Before turning the power ON
Check Sections “3. Mounting to the Control Panel (pp.12 - 15)” and “4. Wiring (pp.16 - 25)” before
turning the power ON.
(2) After turning the power ON
Set necessary setting items after turning the power ON.
Refer to Sections “5. Outline of Key Operation and Each Mode (pp.26-28)”, “6. Initial Settings (pp.
29-36)”, “7. Basic Settings and Operation (pp.37-42)” and “8. Explanation of Setting
Items” (pp.43-85).
(3) Selecting a pattern number
There are 2 methods for selecting a pattern number:
Using the PTN key, or using Event input
Pattern numbers selected by Event input have priority over pattern numbers selected by the key.
To select pattern numbers by keypad, make sure all Event inputs are in OFF (Open) status.
• Using the
PTN
key
Select a pattern from 1 – 10 in Program control STOP (in Standby) with the PTN key.
• Using Event input
If /001 (Pattern number selection) is selected in [Event input DI1 allocation] and [Event
input DI2 allocation]:
Select a pattern from 2 – 4, depending on ON (Closed) or OFF (Open) status between
Event input DI1/DI2 terminal and SG terminal.
Select pattern 1 or a pattern from 5 – 10 with the PTN key.
Signal edge action is engaged. However, when power is turned ON, level action is engaged.
If
/001
(Pattern number selection) is selected only in [Event input DI1 allocation]:
(e.g.) To select Pattern 2, close (ON)
9
and
12
.
(Table 9.1.1-1)
Pattern
number
Terminal
number
* 2
9
Event input DI1
OFF (Open) ON (Closed)
* This number will be selected by keypad.
If
/001
(Pattern number selection) is selected only in [Event input DI2 allocation]:
(e.g.) To select Pattern 2, close (ON)
8
and
12
.
(Table 9.1.1-2)
Pattern
number
Terminal
number
* 2
8
Event input DI2
OFF (Open) ON (Closed)
* This number will be selected by keypad.
