Factory Default
Setting Item, Function, Setting Range
dp//
/ ///0
Decimal point place
• Selects decimal point place.
• Selection item:
///0 No decimal point
//0.0 1 digit after decimal point
/0.00 2 digits after decimal point
0.000 3 digits after decimal point
Available only when DC voltage or current input is selected in [Input type].
evo1
/ /000
Event output EV1 allocation
• Selects Event output EV1 from the table below.
• If Event output EV1 is changed, some setting items will be initialized. Refer to
Section “9.6 Items to be Initialized by Changing Settings” (p.104).
• Selection item:
/000 No event
/001 Alarm output, High limit alarm
/002 Alarm output, Low limit alarm
/003 Alarm output, High/Low limits alarm
/004
Alarm output, High/Low limits independent alarm
/005
Alarm output, High/Low limit range alarm
/006
Alarm output, High/Low limit range independent alarm
/007 Alarm output, Process high alarm
/008 Alarm output, Process low alarm
/009
Alarm output, High limit with standby alarm
/010
Alarm output, Low limit with standby alarm
/011
Alarm output, High/Low limits with standby alarm
/012
Alarm output, High/Low limits with standby independent alarm
/013 Heater burnout alarm output (when C5W, EIW or W option is
ordered):
Detects load current value with CT (current transformer), and
turns ON if it is lower than heater burnout alarm value.
/014 Loop break alarm output:
Sets Loop break alarm time and span.
If the PV does not reach the Loop break alarm span setting within
the time allotted to assess the Loop break alarm (after the MV
has reached 100% or the OUT high limit value), the alarm output
is turned ON. If the PV does not drop to the Loop break alarm
span setting within the time allotted to assess the Loop break
alarm (after the MV has reached 0% or the OUT low limit value),
the alarm output is turned ON.
/015 Time signal output:
Turns ON during program control RUN, by setting Time signal
output OFF time and ON time within total time in one pattern.
/016 Output during AT:
Turns ON duringAT.
/017 Pattern end output:
Turns ON after Program control ends, and remains ON during
the time set in [Pattern end output time].
