Setting Item, Function, Setting Range
_pid
1 ///1
PTN/STEP
indicator 9
lights up.
Step 9 PID block number
• Selects PID block number used for Step 9.
• Selection item:
1 to 10
temp
1 ///0
PTN/STEP
indicator 10
lights up.
Step 10 SV
• Sets Step 10 SV.
Step SV is a value (SV) at the end of the step.
• Setting range:
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 10
lights up.
Step 10 time
• Sets Step 10 time.
Step time is the processing time of the step.
• Setting range:
----, 00:00 to 99.59 (Time unit follows the selection in [Step time unit].)
If the key is pressed at 00:00, ---- will appear.
If ---- is set, Fixed value control will be performed using Step 10 SV.
_pid
1 ///1
PTN/STEP
indicator 10
lights up.
Step 10 PID block number
• Selects PID block number used for Step 10.
• Selection item:
1 to 10
rept
1 ///0
PTN/STEP
indicator turns off.
Number of repetitions
• Sets the number of repetitions for the selected Pattern 1
• Setting range:
0 to 10000
chin
1 ----
PTN/STEP
indicator turns off.
Pattern link
• Selects whether to link Pattern 2 to currently selected pattern 1.
If Pattern 10 is selected, Pattern 1 can be linked, and selects whether to link
Pattern 1.
Randomly selected pattern numbers (Pattern 1 and Pattern 5) cannot be
linked.
For repetitions of linked pattern, the whole linked pattern will be repeated as
many times as set in [Number of repetitions].
(e.g.) If patterns 1 and 2 are linked, and if the number of repetitions of pattern
1 is set to 2 times, the whole linked pattern (Patterns 1 and 2) will be
repeated twice.
• Selection item:
---- Pattern link Disabled
chin Pattern link Enabled
At this stage, settings for Pattern setting mode are complete.
Press the RST key. The unit reverts to RUN mode.
