Assembly and Installation
Subject to change without notice
3.5.1.3 Mounting MCUP on the sun roof
The appropriate mounting kit for the mounting of the MCUP on the sun roof can be found in
Table 3.
Figure 52 Mounting MCUP on the sun roof
1 2
3
4
5
