Assembly and Installation
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 107
Subject to change without notice
Table 3 Mounting kits for sun roof MCUP
Frame MCUP type Mounting kit
Orange (1)
MCUP Compact
Mounting kit MCUP
Size
A,B,C,D
Red (2)
MCUP Medium
Mounting kit MCUP
Size
A,B,C,D
Green (3)
MCUP STAHL, Size 4 (with or
without terminal
compartment)
Mounting kit MCUP
Size
A,B,C,D
