SICK FLOWSIC100 Flare User Manual

Assembly and Installation
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 135
Subject to change without notice
1)
: normal closed
2)
: normal open
3)
: Use only according to consultation with the manufacturer
Terminal Marking on the processor board Function Voltage rating
Ampere rat-
ing
81, 83 A, gnd Interface 2 (reserve, not used)
82, 83 B, gnd
84, 86 +Us, gnd
85, 86 -Us, gnd
87
Not planned for use
88
89
90
P1 P1 service USB Port
