212 FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH
Specifications
Subject to change without notice
9)
: On request; use for zone 1 only FLOWSIC100 EX-S and FLOWSIC100 EX-PR
10)
: Sender/receiver units with ex group IIC T6: - 40 ... +55 °C (- 40 ... 131 °F); option: - 50 ... +55 °C (- 58 ... 131 °F);
IIC T6 not for gas temperature > 80 °C
11)
: For some device configurations the temperature range is reduced. The permitted temperature range is indicated on the device
label.
MCUP Zone 1, Aluminium housing:
-40 ... +55 °C ( -40 ... +131 °F) - ATEX / IECEx
-55 ... +55°C ( -67 ... +131°F) für 24V DC - ATEX / IECEx on request
MCUP Zone 1, stainless steel housing:
-20 ... +40 °C ( -4 ... +104 °F) - ATEX
-20 ... +40 °C ( -4 ... +104 °F) - IECEx
-20 ... +55 °C ( -4 ... +131 °F) - ATEX on request
MCUP Zone2/DIV2 (24 V version)
-40 ... +60°C (-40 ... +140 °F) - Group A, B, C, D T4
MCUP Zone 2/DIV 2 (115 V/230 V version)
-25°C...60°C (-13...+140°F) - Group A,B,C, D T4
MCUP Div 1,
-25 ... +50°C (-13 ... +122 °F) - Group A, B, C, D
-50 ... +50°C (-58 ... +122 °F) - Group C, D
12)
: IP67 for sender/receiver units without junction box only.
13)
: Additional inputs/outputs when using optional modules.
14)
: Replacement fuses T 2 A are part of delivery. Ex-protected control units contain a separate note on label of the fuse type.
