214 FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH
Specifications
Subject to change without notice
Sender/receiver units FLSE100-EXS according to ATEX for Ex zone 1/zone 2, non-
retractable
1
,
2
Fig. 140 Sender/receiver unit FLSE100-EXS Master
Fig. 141 Sender/receiver unit FLSE100-EXS Slave
1 For part nos. see → p. 225, 6.2.4
2 Process connections to fit flange 2" CL150 RF acc. to ASME B16.5. DN50 PN16 form B1 acc. to EN
1092-1 available as option
A
A
56.5 103 155.5 150
A -A
120
48
Ø 120.7
Ø 150
171.5 150
48
A
A
A -A
Ø 120.7
Ø 150
