SICK FLOWSIC100 Flare User Manual

Specifications
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 263
Subject to change without notice
Fig. 192 Materials
Vervielfaeltigung dieser Unterlage sowie Verwertung und Mitteilung ihres Inhaltes unzulaessig, soweit nicht ausdruecklich zugestanden. Zuwiderhand- lungen sind strafbar und verpflichten zu Schadenersatz (LitUrhG, UWG, BGB). Alle Rechte fuer den Fall der Patenterteilung oder GM-Eintragung vorbehalten.
A4_Formblatt_ME10.CDR
SICK Engineering GmbH
Bergener Ring 27
01458 Ottendorf-Okrilla
Verteildatum: Page
Norm-Typ/DIN
Ersatz für:
Änderung
gepr. gez.
Tag
Name
Ind. Tag Name
Maßstab:
Werkstoff Ersetzt durch:
Gepr.
Ursprung:
2008-08-05 MKO
E_41944
5of5
Kochan
Manufacturer drawing FLSE100-EX/-EXRE
Suitability of Materials *) Medium**) Ultrasonic
transducer material
Sealing material in the retraction flange ***)
SS Ti HS FKM
Viton
TM
-40°C up to +180°C
EPDM Vistalon
TM
-50°C up to +100°
FFKM Kalrez
TM
-15°C up to +280°C
air / like air +++ +++ +++ +++ +++ +++ HF - - +++ ++ - +++ O2 +++ + +++ ++ + +++ water steam up to 100°C +++ +++ +++ - +++ +++ water steam up to 280°C +++ +++ +++ - - +++ CH4 / natural gas +++ +++ +++ +++ - +++ sour gas + +++ +++ + +++ +++ CO2 +++ +++ +++ +++ + +++ flare gas +++ +++ +++ +++ +++ +++ Cl2 + - +++ ++ - +++ H2 +++ + +++ +++ +++ +++ NH4 +++ +++ +++ - +++ +++ +++ very good ++ good + conditional good - not suitable SS - stainless steel group 4 ; Ti - titanum grade2 / grade5 HS – hastelloy
*) For information only. Suitability have to be checked by the user **) Rated gas temperature and MWP see marking plate ***) For retractable ultrasonic transducer only.
Indicated in the type code, see marking plate. Leacking O-rings have to be changed by the
SICK service only.
2009-08-18
Kochan
Kochan
MKO
MKO
A
B
2009-12-04
2010-05-26
