32 FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH
Product Description
Subject to change without notice
Assignment device type - type of sender receiver unit
Sender/receiver unit versions
● Non-retractable sender/receiver units
Cannot be installed or removed while the plant is in operation.
● Retractable sender/receiver units
Can be installed or removed while the plant is in operation. Installation on the pipeline is
performed with nozzle and ball valve (
→ pg. 112, § 3.6.2).
Option: Venting ball valve for sender/receiver unit
Retractable sender/receiver units can be delivered with optional "venting valve" equipment
(ball valve) at the retraction flange.
● The venting ball valve must be installed by the manufacturer. Installation outside the
factory is not possible.
● The connection for the venting valve is closed with a blind screw by the factory.
Option: Connection for condensation drain at sender/receiver unit
Optional connection for condensation drain can be used under consideration of following
restrictions only:
● Drain only over closed drain system. Drain system (piping etc.) is not included as part of
delivery SICK.
● Drain system must be designed considering the process conditions (pressure,
temperature, gas composition).
All relevant safety regulations, standards and guidelines must be considered when using
the condensation drain. The use of the condensation drain is the sole responsibility of the
plant operator.
Device type Name of sender/receiver unit
FLOWSIC100 EX-S FLSE100-EXS
FLOWSIC100 EX FLSE100-EX
FLOWSIC100 EX-RE FLSE100-EXRE
FLOWSIC100 EX-PR FLSE100-EXPR
WARNING: Danger of leakage
 Do not remove the blind screw at the connection for the venting valve!
WARNING: Danger in case of incorrect use
Retractable sender/receiver units without optional venting may only be used
for non-hazardous gases (not aggressive/toxic/explosive, low temperatures) or
otherwise only when the plant operator takes suitable protective measures and
safety precautions for safe venting.
 Venting is only permitted if the process ball valve of the system is closed
tightly!
