Iso-center with ultrasound 6 - 11
Siemens AG SPL1-130.840.02 Page 11 of 16 MODULARIS Uro Plus
Medical Solutions Rev. 03 04.05 CS PS 24
Checking the distance: Side (16b/Fig. 16)
• Press the key twice (cross "+1" is not needed for this measurement).
• Move the cross "+2" using the track ball onto the horizontal axis of the target line at the
height of isocenter (C/Fig. 16).
• Press the key.
• Move the cross using the track ball horizontally into the center of the white area of the
isocenter phantom.
• If the center point of the white area (16b/Fig. 16) is not in the center
(permitted difference: +
0.5 mm from the center):
- Make a note of the value of D2 (with mathematical sign):
If the display of the ball (16b/Fig. 16) appears to the left of the isocenter, the correction
value must have a negative sign in front (to the right is a positive sign in front).
- Press the key.
- Press the "F4" key.
- Press the "5" key.
- Select "MUP" with the track ball.
- Press the key.
- Enter the password.
- Use the track ball to select the appropriate probe during image tilt.
- Press the key.
- Enter half the value of D2 (H/Fig. 16).
Example:(H/Fig. 16): D2 = 1,2 mm
⇒ Enter: -06 .
- Press the key.
- Press the key twice.
- Check the difference; if white area (16b/Fig. 16) is not in the center of the isocenter,
repeat the procedure.
• Press the key.
• After adjusting the mount for the ultrasound probe, attach it on the mount (7/Fig. 1).
For each probe, check whether the adjustment in this position is also okay. Do not make
any change to the image tilt adjustment.
• Following the check, store the parts in the appropriate transport cases.
German: Bildneigung Sektor
Bildneigung Array
French: Basculement d’image sondes sect.
Basculement d’image sondes conv.
English: Image Tilt Sector
Image Tilt Array
Spanish: Incl. imagen transd. sect mecanico
Inclinar imagen transductor curvo
