Input bits
Index German name English name Description
0 RELEASE RELEASE Release
1 TRAVEL TRAVEL Travel
2 OM_POS OM_POS Positioning mode
3 OM_MAN OM_MAN Manual mode
4 OM_SNL OM_SNL Sway neutralization load position mode
5 OM_SND OM_SND Sway neutralization trolley position mode
6 OM_SAM OM_SAM Semi-automatic mode
7 SC_ON_TROLLEY SC_ON_TROLLEY Activate sway control
8 LS_FW/UP LS_FW/UP Limit switch
9 LS_BW/DN LS_BW/DN Limit switch
10 PRELS_FW/UP PRELS_FW/UP Prelimit switch
11 PRELS_BW/DN PRELS_BW/DN Prelimit switch
12 BRAKE_CLOSED BRAKE_CLOSED Brake closed
13 SC_WHEN_STOP_TROL‐
LEY
SC_WHEN_STOP_TROL‐
LEY
Sway control when stopping
14 CONTROLLED_STOP CONTROLLED_STOP Controlled stopping
15 FLYING TROLLEY FLYING_TROLLEY Flying trolley
21 FAST_STOP FAST_STOP Fast stop
100 PARSET_BIT0 PARSET_BIT0 Parameter set bit 0
101 PARSET_BIT1 PARSET_BIT1 Parameter set bit 1
102 NO_WAIT_POS NO_WAIT_POS No waiting position
103 PRG_OBST PRG_OBST Program obstacles
104 DEL_OBST DEL_OBST Delete obstacles
106 HOIST_MAN HOIST_MAN Hoist manual mode
107 START_2D_CALC START_2D_CALC Start 2D calculation
108 LOCKED_BIT0 LOCKED_BIT0 Locked bit 0
109 LOCKED_BIT1 LOCKED_BIT1 Locked bit 1
110 SLACKROPE SLACKROPE Slack rope
111 BAYSCANNER_VALID BAYSCANNER_VALID Bay scanner valid
112 LEARN_PROFILE_ON LEARN_PROFILE_ON Profile learning active
113 LEARN_PROFILE_RESET LEARN_PROFILE_RESET Reset profile learning
114 IMPNT_EXT_ACTIVE IMPNT_EXT_ACTIVE External immersion point active
115 SPREADERS_COUPLED SPREADERS_COUPLED Spreaders coupled
120 LEARN_PARK_POS LEARN_PARK_POS Learn parking position
121 LEARN_LASH_PLATF LEARN_LASH_PLATF Learn lashing platform
122 SAVE_LOGGER SAVE_LOGGER Save logger
123 USE_LASH_PLATF USE_LASH_PLATF Use lashing platform
124 STACK_FORM_BIT0 STACK_FORM_BIT0 Stack form bit 0
125 STACK_FORM_BIT1 STACK_FORM_BIT1 Stack form bit 1
126 INIT_TARGETS INIT_TARGETS Initialize targets
127 CYCLING CYCLING Cycling
Appendix
A.5 Variable signals
SC integrated STS, GSU
Operating Instructions, 07/2019, A5E48271265B AA 439
