If the converter does not output alarm A07991, switch o󹪜 the motor as described below, and
switch over the converter control from HAND to AUTO.
Switch on the motor to start the rotating measurement.
During motor data identi󹪝cation 󹪞ashes on the BOP‑2.
The motor data identi󹪝cation can take up to2minutes depending on the rated motor power.
Depending on the setting, after motor data identi󹪝cation has been completed, the converter
switches o󹪜 the motor - or it accelerates it to the setpoint.
If required, switch o󹪜 the motor.
Disable the control priority via the operator panel.
You have completed the motor data identi󹪝cation.
Quick commissioning has been completed once the motor data identi󹪝cation has been
successfully completed.
5.5 Quick commissioning with a PC.
The screen forms that are shown in this manual show generally valid examples. The number of
setting options available in screen forms depends on the particular converter type.
Overview
To be able to perform quick commissioning using a PC, you need to do the following:
1. Creating a project
2. Integrating the converter into the project
3. Go online and start the quick commissioning
5.5.1 Creating a project
Creating a new project
Procedure
1. Start the Startdrive commissioning software.
2. In the menu, select "Project" → "New…".
3. Specify a name of your choice for the project.
You have created a new project.
Commissioning
5.5Quick commissioning with a PC.
SINAMICS G120C Converters
138 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK
