4.10.11.3 Installing the GSD
Procedure
1. Save the GSD on your PC using one of the following methods.
– With Internet access:
GSD (http://support.automation.siemens.com/WW/view/en/22339653/133100)
– Without Internet access:
Insert a memory card into the converter.
Set p0804 =12.
The converter writes the GSD as zipped 󹪝le (*.zip) into directory /SIEMENS/SINAMICS/
DATA/CFG on the memory card.
2. Unzip the GSD 󹪝le on your computer.
3. Import the GSD in the engineering system of the controller.
You have now installed the GSD 󹪝le in the engineering system of the controller.
4.10.11.4 Set the PROFIBUS address
Valid address area: 1 … 125
You have the following options for setting the address:
• Using the address switch on the Control Unit:
([DPSOH



2II
%LW
%LW
%LW
%LW
%LW
%LW
%LW
2II2Q2Q
Figure4-46 Address switch with example for bus address 10
The address switch has priority over the other settings.
• With a commissioning tool, e.g. an operator panel, via parameter p0918 (factory setting:
p0918=126).
It is only possible to change p0918 if an invalid address is set in the address switch.
Overview of the interfaces (Page82)
