Siemens SINAMICS G120C DP User Manual

5DWHGSRZHURIWKH
LQYHUWHU
&RQQHFWLRQFURVVVHFWLRQWLJKWHQLQJWRUTXH
%UDNLQJUHVLVWRU
7HPSHUDWXUHFRQWDFW
1P
1P
bN:bN:
bN:
PPt
PPt
OEILQ
1P
OEILQ
PPt
1P
OEILQ
1P
1P
1P
OEILQ
OEILQ
OEILQ
OEILQ
bN:
ಹ
ಹ
ಹ
ಹ
ಹ
ಹ
PPt
PPt
PPt
bN:
bN:
bN:
bN:
N:
N:
N:
N:
553(
$:*
$:*
$:*
$:*
$:*
$:*
PPt
$:*
4.9.5 Branch circuit protection
Table 4-7 Branch circuit protection according to the IEC standard and UL standard
Frame size Rated power Article number
Converter Fuse according to
the IEC standard
Max. rated current
of the fuse accord‐
ing to UL standard,
Class J
1)
FSAA 0.55kW
0.75kW
1.1kW
1.5kW
2.2kW
6SL3210‑1KE11‑8…
6SL3210‑1KE12‑3…
6SL3210‑1KE13‑2…
6SL3210‑1KE14‑3…
6SL3210‑1KE15‑8…
3NA3803 10A
FSA 3kW
4kW
6SL3210‑1KE17‑5…
6SL3210‑1KE18‑8…
3NA3805 15A
FSB 5.5kW
7.5kW
6SL3210‑1KE21‑3…
6SL3210‑1KE21‑7…
3NA3812 35A
FSC 11kW
15kW
18.5kW
6SL3210‑1KE22‑6…
6SL3210‑1KE23‑2…
6SL3210‑1KE23‑8…
3NA3822 60A
FSD 22kW 6SL3210‑1KE24‑4… 3NA3824 70A
30kW 6SL3210‑1KE26‑0… 3NA3830 90A
37kW 6SL3210‑1KE27‑0… 3NA3830 100A
45kW 6SL3210‑1KE28‑4… 3NA3832 125A
FSE 55kW 6SL3210‑1KE31‑1… 3NA3836 150A
FSF 75kW 6SL3210‑1KE31‑4… 3NA3140 200A
90kW 6SL3210‑1KE31‑7… 3NA3142 250A
110kW 6SL3210‑1KE32‑1… 3NA3250 300A
132kW 6SL3210‑1KE32‑4… 3NA3252 350A
1)
The stated fuses are only permissible with a cabinet volume ≥0.36m³
You can 󹪝nd information about other permissible overcurrent protection devices on the
Internet.
Installing
4.9Connect the line supply, motor and braking resistor
SINAMICS G120C Converters
76 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
