Siemens SINAMICS G120C DP User Manual

11.11.3 Output reactor
Preconditions for using reactors:
• Maximum permissible output frequency of the converter: 150Hz
• Converter pulse frequency: 4kHz
The assignment of a suitable output reactor to the converter is provided in the following
Chapter:
Optional components (Page34)
Dimensions and mounting dimensions:
Mounting base components (Page46)
Mounting the output reactor (Page58)
Table 11-20 Technical data of the output reactor
Article no. 6SE6400-3TC00-4AD2 6SL3202-0AE16-1CA0 6SL3202-0AE18-8CA0
Inductance 2.5mH 2.5mH 1.3 mH
Power loss at 50/60 Hz 25W 90W 80 W
Degree of protection IP20 IP20 IP20
Weight 0.8kg 3.4 kg 3.9 kg
Table 11-21 Technical data of the output reactors
Article no. 6SL3202-0AE21-8CA0 6SL3202-0AE23-8CA0 6SE6400-3TC07-5ED0
Inductance 0.54 mH 0.26 mH 0.3 mH
Power loss 80 W 110 W 277W
Degree of protection IP20 IP20 IP20
Weight 10.1 kg 11.2 kg 26.7 kg
Table 11-22 Technical data of the output reactors
Article no. 6SE6400‑3TC14‑5FD0 6SL3000‑2BE32‑1AA0 6SL3000‑2BE32‑6AA0
Inductance 0.2 mH --- ---
Power loss 469W 486W 500W
Degree of protection IP20 IP00 IP00
Weight 55.9kg 60kg 66kg
Technical data
11.11Accessories
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 443

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
