Siemens SINAMICS G120C DP User Manual

8.24 Motor protection with temperature sensor
Overview
The converter can evaluate one of the following sensors to protect the motor against
overtemperature:
˽

702725
702725
702725
702725
702725
702725
• KTY84 sensor
• Temperature switch (e.g. bimetallic switch)
• PTC sensor
• Pt1000 sensor
Function description
KTY84 sensor
NOTICE
Overheating of the motor due to KTY sensor connected with the incorrect polarity
If a KTY sensor is connected with incorrect polarity, the motor can be damaged by overheating,
as the converter cannot detect a motor overtemperature condition.
• Connect the KTY sensor with the correct polarity.
Using a KTY sensor, the converter monitors the motor temperature and the sensor itself for
wire-break or short-circuit:
• Temperature monitoring:
The converter uses a KTY sensor to evaluate the motor temperature in the range from
-48°C...+248°C.
Set the temperature for the alarm and fault thresholds with parameter p0604 or p0605.
– Overtemperature alarm (A07910):
-motor temperature>p0604 and p0610=0
– Overtemperature fault (F07011):
The converter responds with a fault in the following cases:
-motor temperature> p0605
-motor temperature>p0604 and p0610> 0
• Sensor monitoring (A07015 or F07016):
– Wire-break:
The converter interprets a resistance >2120Ω as a wire-break and outputs the alarm
A07015. After 100milliseconds, the converter changes to the fault state with F07016.
– Short-circuit:
The converter interprets a resistance <50Ω as a short-circuit and outputs the alarm
A07015. After 100milliseconds, the converter changes to the fault state with F07016.
Advanced commissioning
8.24Motor protection with temperature sensor
SINAMICS G120C Converters
340 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
