Siemens SINAMICS G120C DP User Manual

The converter evaluates its control commands depending on digital input DI3:
• Via a 󹪝eldbus from a central control system
• Via the converter digital inputs at the installation.
Note
The converter requires approx. 4ms to switch over the command data set.
Parameters
Number Name Factory setting
p0010 Drive commissioning parameter 󹪝lter 1
r0050 CO/BO: Command data set CDS e󹪜ective -
p0170 Number of command data sets (CDS) 2
p0809[0…2] Copy command data set CDS 0
p0810 BI: Command data set selection CDS bit 0 Dependent on the
converter
p0811 BI: Command data set selection CDS bit 1 0
8.13 Motor holding brake
Overview
The motor holding brake holds the motor in position when it is switched o󹪜.
When the "Motor holding brake" function is correctly set, the motor remains switched on as
long as the motor holding brake is open. The converter only switches the motor o󹪜 when the
motor holding brake is closed.
Advanced commissioning
8.13Motor holding brake
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 245

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
