• [11]: The same setting as [1]. The motor accelerates to the currently set setpoint after the
motor data identication.
• [12]: The same setting as [2]. The motor accelerates to the currently set setpoint after the
motor data identication.
Calculating the motor parameters: Select "Complete calculation".
Set the check mark for "RAM data to EEPROM (save data in the drive)" to save your data in the
converter so that it is not lost if the power fails.
Select "Finish".
You have entered all of the data that is necessary for the quick commissioning of the
converter.
❒
Commissioning
5.5Quick commissioning with a PC.
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 147
