Table 8-9 Set two-wire control, ON/reverse in quick commissioning
Parameter Description
p0015=12 Macro drive unit
Assigning digital inputs to the commands:
• Digital input0: ON/OFF1
• Digital input1: Reversing
Default setting of the interfaces (Page92)
Parameter
Parameter Description Factory setting
p0840[C] BI: ON/OFF (OFF1) 0
p1113[C] BI: Setpoint inversion 0
r0722.0…n CO/BO: CU digital inputs, status -
p3334 2/3 wire control selection
0: Two-wire control, ON/reverse
0
Advanced commissioning
8.5Controlling clockwise and counter-clockwise rotation via digital inputs
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 203
