Siemens SINAMICS G120C DP

Table 8-15 Set two-wire control, clockwise/counterclockwise rotation 2 in quick commissioning
Parameter Description
p0015=18 Macro drive unit
Assigning digital inputs to the commands:
• Digital input0: ON/OFF1 clockwise rotation
• Digital input1: ON/OFF1 counter-clockwise rotation
Default setting of the interfaces (Page92)
Parameter
Parameter Description Factory setting
r0722.0…n CO/BO: CU digital inputs, status -
p0840[C] BI: ON/OFF (OFF1) 0
p1113[C] BI: Setpoint inversion 0
p3330[C] BI: 2/3 wire control command 1 0
p3331[C] BI: 2/3 wire control command 2 0
r3333.0…n CO/BO: 2/3 wire control control word -
p3334 2/3 wire control selection
2: Two-wire control, clockwise/counterclockwise rotation 2
0
Advanced commissioning
8.5Controlling clockwise and counter-clockwise rotation via digital inputs
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 207
