Siemens SINAMICS G120C DP User Manual

• IND, bit 0…7 (subindex): = 90 hex (o󹪜set 6000 corresponds to 90 hex)
• Because you want to read the parameter value, words 3 and 4 in the parameter channel for
requesting the parameter value are irrelevant. They should be assigned a value of 0, for
example.
3DUDPHWHUFKDQQHO
3:(KLJKUGZRUG3:(ORZWKZRUG,1'QGZRUG
6XELQGH[3DUDPHWHUQXPEHU3DJHLQGH[3DUDPHWHUYDOXH
3.(VWZRUG
3DUDPHWHUYDOXH3DUDPHWHUYDOXH
$.





Figure8-16 Telegram for a read request from r7841[2]
PNU (parameter number) and page index
Parameter number PNU Page index
0000 … 1999 0000 … 1999 0hex
2000 … 3999 0000 … 1999 80hex
6000 … 7999 0000 … 1999 90hex
8000 … 9999 0000 … 1999 20hex
10000 … 11999 0000 … 1999 A0hex
20000 … 21999 0000 … 1999 50hex
30000 … 31999 0000 … 1999 F0hex
60000 … 61999 0000 … 1999 74 hex
Subindex
For indexed parameters, the parameter index is located in subindex as hexadecimal value.
PWE: Parameter value or connector
Parameter values or connectors can be located in the PWE.
Table 8-31 Parameter value or connector
 PWE 1 PWE 2
Parameter value Bit 15…0 Bit 15… 8 Bit 7…0
0 0 8-bit value
0 16-bit value
32-bit value
Connector Bit 15…0 Bit 15…10 Bit9…0
Number of the connector 3F hex The index or bit 󹪝eld
number of the connec‐
tor
Advanced commissioning
8.6Drive control via PROFIBUS or PROFINET
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 225

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
