Siemens SINAMICS G120C DP User Manual

Parameter
Number Name Factory setting
p0922 PROFIdrive PZD telegram selection 1
r2050[0…11] CO: PROFIdrive PZD receive word -
p2051[0…16] CI: PROFIdrive PZD send word 0 or dependent on
the converter
r2053[0…16] PROFIdrive diagnostics send PZD word -
r2060[0…10] CO: PROFIdrive PZD receive double word -
p2061[0…15] CI: PROFIdrive PZD send double word 0
r2063[0…15] PROFIdrive diagnostics PZD send double word -
r2067 PZD maximum interconnected
[0] Receive (r2050, r2060)
[1] Send (p2051, p2061)
-
p2079 PROFIdrive PZD telegram selection extended 1
p2080[0…15] BI: Binector-connector converter, status word 1 [0] 899
[1] 899.1
[2] 899.2
[3] 2139.3
[4] 899.4
[5] 899.5
[6] 899.6
[7] 2139.7
[8] 2197.7
[9] 899.9
[10] 2199.1
[11] 1407.7
[12] 0
[13] 2135.14
[14] 2197.3
[15] 2135.15
r2090.0…15 BO: PROFIdrive receive PZD1 bit by bit -
r2091.0…15 BO: PROFIdrive PZD2 receive bit-serial -
r2092.0…15 BO: PROFIdrive PZD3 receive bit-serial -
r2093.0…15 BO: PROFIdrive PZD4 receive bit-serial -
Advanced commissioning
8.6Drive control via PROFIBUS or PROFINET
SINAMICS G120C Converters
230 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
