Siemens SINAMICS G120C DP User Manual

Parameter
Number Name Factory setting
p1055[C] BI: Jogging bit 0 Depending on the
converter
p1056[C] BI: Jogging bit 1 Depending on the
converter
p1058[D] Jogging 1 speed setpoint 150rpm
p1059[D] Jogging 2 speed setpoint -150rpm
p1082[D] Maximum speed 1500rpm
p1110[C] BI: Inhibit negative direction Depending on the
converter
p1111[C] BI: Inhibit positive direction 0
p1113[C] BI: Setpoint inversion 0
p1120[D] Ramp-function generator ramp-up time Depending on the
converter
p1121[D] Ramp-function generator ramp-down time Depending on the
converter
Parameter
Table 8-33 Jog settings
Parameter Description Factory setting
p1055[C] BI: Jogging bit 0 0
p1056[C] BI: Jogging bit 1 0
p1058[D] Jogging 1 speed setpoint 150rpm
p1059[D] Jogging 2 speed setpoint -150rpm
p1082[D] Maximum speed 1500rpm
p1110[C] BI: Inhibit negative direction 0
p1111[C] BI: Inhibit positive direction 0
p1113[C] BI: Setpoint inversion 0
p1120[D] Ramp-function generator ramp-up time 10s
p1121[D] Ramp-function generator ramp-down time 10s
Advanced commissioning
8.10Jogging
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 241

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
