Siemens SINAMICS G120C DP User Manual

Chapter In this section you will 󹪝nd answers to the following questions:
Alarms, faults and system
messages (Page361)
• How are converter components replaced?
• How is the 󹪝rmware version of the converter changed?
• What must be done after a converter replacement if the safety functions of the
converter are active?
Technical data (Page421)
• What is the converter technical data?
• What do "High Overload" and "Low Overload" mean?
• What e󹪜ect do the installation altitude or ambient temperature have on the con‐
verter, for example?
Appendix (Page449)
• What are the new functions of the current 󹪝rmware?
• How is the converter operated using the BOP-2 Operator Panel?
• How can signal interconnections be changed in the converter 󹪝rmware?
• What does "BiCo technology" mean?
• Where can I 󹪝nd additional information about the converter?
Introduction
2.2Guide through the manual
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 25

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
