Siemens SINAMICS G120C DP User Manual

Parameter
Table 8-43 Basic setup of motorized potentiometer
Number Name Factory setting
p1035[C] BI: Motorized potentiometer setpoint higher 0
p1036[C] BI: Motorized potentiometer setpoint lower Dependent on the
converter
p1040[D] Motorized potentiometer start value 0rpm
p1047[D] Motorized potentiometer, ramp-up time 10s
p1048[D] Motorized potentiometer, ramp-down time 10s
r1050 Motorized potentiometer, setpoint after the ramp-function
generator
- rpm
p1070[C] CI: Main setpoint Dependent on the
converter
p1071[C] CI: Main setpoint scaling 1
r1073 CO: Main setpoint active - rpm
p1075[C] CI: Supplementary setpoint 0
p1076[C] CI: Supplementary setpoint scaling 1
Table 8-44 Extended setup of motorized potentiometer
Number Name Factory setting
p1030[D] Motorized potentiometer con󹪝guration 0000 0110 bin
p1037[D] Motorized potentiometer, maximum speed 0rpm
p1038[D] Motorized potentiometer, minimum speed 0rpm
p1043[C] BI: Motorized potentiometer, accept setting value 0
p1044[C] CI: Motorized potentiometer, setting value 0
Advanced commissioning
8.17Setpoints
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 275

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
