Siemens SINAMICS G120C DP

Requirement
The following preconditions apply:
• You know the password for the converter safety functions.
• The converter power supply has been switched on.
• The converter settings are not protected against copying.
Download with active know-how protection with copy protection (Page401)
Function description
Procedure
1. Attach the Operator Panel to the converter.
2. Start the download.
8S'RZQORDG
0HQX
3DUDPHWHUV6HWXS'LDJQRVWLFV
8S
'RZQORDG
([WUDV6XSSRUW
'RZQORDGSDQHOWRGULYH
8SORDGGULYHWRSDQHO
'HOHWHSDQHOSDUDPHWHUVHW
'ULYHWRPHPRU\FDUG
0HPRU\FDUGWRGULYH
5HQDPHSDUDPHWHUVHW
3. Wait until the transfer is complete.
4. After loading, check whether the converter outputs Alarm A01028.
$FWLYHIDXOWVDODUPV
+LVWRU\
,GHQWLILFDWLRQ0DLQWHQDQFH
,2VWDWXV
&RPPXQLFDWLRQVVWDWXV
,2VLPXODWLRQ
'ULYHHQDEOHV
'LDJQRVWLFV
0HQX
3DUDPHWHUV6HWXS'LDJQRVWLFV
8S
'RZQORDG
([WUDV6XSSRUW
– Alarm A01028:
The loaded settings are not compatible with the converter.
Delete the alarm with p0971=1.
Recommission the drive.
– No alarm A01028: Proceed with the next step.
5. Back up the settings so that they are protected against power failure.
0HQX
3DUDPHWHUV6HWXS'LDJQRVWLFV
8S
'RZQORDG
([WUDV6XSSRUW
([WUDV
'ULYHIDFWRU\UHVHW
6DIHIDFWRU\UHVHW
'HIDXOWGDWDVHW
3DUDPHWHUVDYLQJPRGH
6DYH5$0WR520
6WDWXVVFUHHQZL]DUG
'ULYHLGHQWLW\
3DUDPHWHUVHWWLQJV
3DQHOVHWWLQJV
Corrective maintenance
10.2Downloading the converter settings
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 395
