The driven machine is not part of the drive system.
Note
PDS as component of machines or systems
When you install PDS into machines or systems, additional measures may be required so that the
product standards of these machines or systems is complied with. The machine or system
builder is responsible for taking these measures.
Environments and categories
Environments
IEC/EN 61800-3 makes a distinction between the "󹪝rst environment" and "second
environment" - and de󹪝nes di󹪜erent requirements for these environments.
• First environment:
Residential buildings or locations at which the PDS is directly connected to a public low-
voltage supply without intermediate transformer.
• Second environment:
All industrial plant/systems or locations that are connected to the public grid through their
own, dedicated transformer.
Categories
IEC/EN 61800-3 makes a distinction between four drive system categories:
• Category C1:
Drive systems for rated voltages <1000V for unrestricted use in the "󹪝rst environment"
• Category C2:
Stationary PDS for rated voltages <1000V for operation in the "second environment".
Appropriately quali󹪝ed personnel are required to install the PDS. An appropriately trained
and quali󹪝ed person has the necessary experience for installing and commissioning a PDS,
including the associated EMC aspects.
Additional measures are required for operation in the "󹪝rst environment".
• Category C3:
PDS for rated voltages <1000V - only for operation in the "second environment".
• Category C4:
PDS for IT line supplies for operation in complex systems in the "second environment".
An EMC plan is required.
Second environment - category C4
An un󹪝ltered converter corresponds to category C4.
EMC measures in the "second environment", category C4, are implemented on the basis of
an EMC plan at the system level.
EMC-compliant setup of the machine or plant (Page39).
Technical data
11.9Electromagnetic compatibility of the converter
SINAMICS G120C Converters
436 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
