Siemens SINAMICS G120C DP User Manual

Mounting the line reactor (Page56)
Table 11-16 Technical data of the line reactors
Article no. 6SE6400-3CC00-2AD3 6SE6400-3CC00-4AD3 6SE6400-3CC00-6AD3
Inductance 2.5mH 2.5mH 2.5mH
Power loss 25W 25W 40W
Degree of protection IP20 IP20 IP20
Weight 1.3kg 1.4kg 1.4kg
Table 11-17 Technical data of the line reactors
Article no. 6SL3203-0CE13-2AA0 6SL3203-0CE21-0AA0 6SL3203-0CE21-8AA0
Inductance 2.5mH 2.5mH 0.5 mH
Power loss 25W 40W 55W
Degree of protection IP20 IP20 IP20
Weight 1.1 kg 2.1 kg 3.0kg
Table 11-18 Technical data of the line reactors
Article no. 6SL3203-0CE23-8AA0 
Inductance 0.3 mH 
Power loss 90W 
Degree of protection IP20 
Weight 7.8kg 
Technical data
11.11Accessories
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 441

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
