Function SINAMICS
G120 G120D
16 The technology controller output can be enabled and disabled during oper‐
ation
- - - -
17 Ramp-function generator remains active with enabled technology controller - - - - - - - -
18 Line contactor control using a digital output of the converter to save energy
when the motor is switched o󹪜
-
19 Fast 󹪞ying restart for PM330 Power Modules:
The "Flying restart" function does not have to wait for the motor demagnet‐
ization time, and identi󹪝es the motor speed without requiring a search op‐
eration.
- - - - - - - -
20 Load torque monitoring extended to include the following functions:
Protection against blocking, leakage and dry running operation in pump
applications
Protection against blocking and broken belts in fan applications
- - - - -
21 Automatic switchover of the real time clock from daylight saving time (sum‐
mer time) to standard time (winter time).
- - - - - - - -
22 New or revised default settings of the interfaces: p0015 macros 110, 112
and 120
- - - - - - - -
23 Expansion of the temperature sensors to include DIN-Ni1000 for analog
inputs AI2 and AI3
- - - - - - - -
24 Communication via AS-Interface.
Default setting of the communication via AS-i: p0015 macros 30, 31, 32 and
34
- - - - - - - -
25 Communication expansion via Modbus:
Adjustable parity bit, access to parameters and analog inputs
- - -
26 Extending communication via BACnet:
Access to parameters and analog inputs
- - - - - - - -
27 The bus error LED for communication via USS and Modbus can be switched
o󹪜
- - -
28 Default of the minimum speed to 20% of the rated motor speed - - - - - - - -
29 For commissioning with an operator panel, the converter automatically
backs up the measured data retentively in the ROM after identi󹪝cation of the
motor data.
30 The result of the energy savings calculation for 󹪞ow machines is available as
a connector
31 New "ppm" unit (parts per million) for unit switching
32 Displaying speeds during commissioning via operator panel in units of Hz
instead of rpm. Conversion from Hz to rpm via p8552
- - - - - - - -
33 Voltage-dependent current limit for 600V devices of Power Module PM330
and PM240-2
- - - - -
Appendix
A.1New and extended functions
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 457
