Siemens SINAMICS S120 Combi Equipment Manual

S120 Combi Power Modules
4.8 Electrical connection
114
SINAMICS S120 Combi
Manual, (GH9), 07/2016, 6SL3097-4AV00-0BP5
4.7.5.5
Technical data
Table 4- 19 Technical data of the external fan unit
6SL3161-0EP00-0AA0
Unit
Value
Input voltage
V
DC
20.4 … 28.8
Power consumption
W
18
Electronics current drawn at 24 V DC
A
0.8
Volumetric rate of air flow m
3
/h 290
Service life
h
50000 at 55 °C
Dimensions (W x H x D)
mm
258 x 104 x 86
Weight
kg
1.5
Degree of protection
IP54
4.8
Electrical connection
4.8.1
Stripped length for the line supply and power cables
Non-prefabricated MOTION-CONNECT power cables must be appropriately prepared before
being connected to the S120 Combi.
Note
Special issue for UL applications
For UL applications, use 60/75
°C copper wires/conductors.
Cables without connection cables for the motor holding brake
1. Cut the cable jacket to dimension A from the table below
2. Strip the single cores U, V, W and PE and crimp on end sleeves with insulation support
Cables with connection cables for the motor holding brake
1. Cut the cable jacket to 250
± 5
mm
2. Cut the single cores U, V, W and PE to dimension A from the table below, strip and crim
p
on e
nd sleeves with insulation support
3. Strip the connection cables for the motor holding brake and screw to the brake connector
