Page #222 background imageLoading...
Page #222 background image
Additional system components
9.2 DRIVE-CLiQ Hub Module DMC20
222
SINAMICS S120 Combi
Manual, (GH9), 07/2016, 6SL3097-4AV00-0BP5
9.1.9
Technical data
Table 9- 15 Technical data
6SL3055-0AA00-3BA.
Unit
Value
Current requirement
X524
(at 24 V DC)
without DRIVE-CLiQ supply
mA 160
Current requirement X514
(at 24 V DC)
without digital outputs and sensor power supply
mA 38
Sensor power supply with and without forced dormant error detection (L1+, L2+, L3+)
Voltage
V
24
Max. load current per output
A
0.5
Max. cable length for the 24 V supply
:
For longer cable lengths, surge protection device
"Weidmüller type No. MCZ OVP TAZ DIODE 24 VDC"
should be used.
m 30
Power loss
W
4.5 at 24 V
PE/ground connection
At the housing with
M4 screw
Weight
kg
Approx. 0.9
9.2
DRIVE-CLiQ Hub Module DMC20
9.2.1
Description
The DRIVE-CLiQ Hub Module DMC20 is a DRIVE-CLiQ component and can be snapped
onto a standard mounting rail (EN 60715). It is only used to connect direct measuring
systems for the feed axes and expansion axes of the S120 Combi.
Note
The DMC20 should also be used if only one feed axis is coupled with a direct measuring
system.
A fixed topology applies when assigning the particular feed axis to a DRIVE-CLiQ interface
(see Section Topology rules for DRIVE-CLiQ (Page 131)) and this must be observed.
