Cabinet design and EMC
12.7 Connection system
302
SINAMICS S120 Combi
Manual, (GH9), 07/2016, 6SL3097-4AV00-0BP5
Table 12- 7 Comparison between MOTION-CONNECT 500 and MOTION-CONNECT 800PLUS DRIVE-CLiQ cables
DRIVE-CLiQ signal cable
MOTION-CONNECT 500
MOTION-CONNECT 800PLUS
Approvals
VDE
cURus or UR/CSA
UR-CSA File No.
1)
in conformance with RoHS
Yes
UL STYLE 2502/CSA-N.210.2-M90
Yes
Yes
Yes
UL STYLE 2502/CSA-N.210.2-M90
Yes
Yes
Rated voltage V
0
/V
in accordance with EN 50395
30 V 30 V
Test voltage, rms
500 V
500 V
Operating temperature at the surface
Permanently installed
Moveable
-20 ... +80 °C
0 ... 60 °C
-20 … +80 °C
-20 … +60 °C
Strain, max.
Permanently installed
Moveable
80 N/mm
2
30 N/mm
2
50 N/mm
2
20 N/mm
2
Smallest bending radius
Permanently installed
Moveable
35 mm
125 mm
35 mm
75 mm
Torsional stress
30°/m absolute
30°/m absolute
Bending operations
100000
10 million
Max. traversing speed
30 m/min
300 m/min
Max. acceleration
2 m/s
2
Up to 50 m/s
2
(3 m)
insulation material
CFC/silicone-free
CFC/halogen-free/silicon-free
Oil resistance
EN 60811-2-1
(mineral oil only)
EN 60811-2-1
Protective jacket
PVC PUR, HD22.10 S2
(VDE 0282, Part 10)
Flame retardant
EN 60332-1-1 to 1-3
EN 60332-1-1 to 1-3
1)
The file number is printed on the cable jacket.
12.7.2
Power cables for motors
12.7.2.1
Approved power cables
Note
Only MOTION
-CONNECT 500 and MOTION-CONNECT 800 power cables are permissible
for the S120 Combi.
